[Technical Parameters of the Entire Vehicle] | |
Body size (mm) | 5640x2000x2615 |
Total weight (KG) | 3800 |
Quality of service (KG) | 2700 |
Automatic boarding stretcher | 1set |
Stretcher guide rail and guide plate | 1set |
Medical oxygen cylinder 10L | 2set |
Oxygen pressure reducing valve | 2 set |
Humidifying bottle | 1 set |
1000W inverter | 1 set |
Power port 220V | 2 set |
Power socket 12V | 2 set |
Flashing lights on both sides | 1 set |
Multifunctional ventilation fan | 1 set |
Long strip lighting | 4 set |
Oblong disinfection lamp | 1 set |
Overhead handrail | 1 set |
Horizontal strip seats | 1 row |
Medical sewage pail | 1 set |
air conditioner. | 1 set |
Left upper PVC hanging cabinet | 1 set |
[Chassis basic configuration] | |
Brand name | Tuyano Fukuda |
Fuel type | Diesel oil |
displacement (ml) | 1968 |
Rated power (KW) | 110 |
Maximum speed (km/h) | 150 |
Front/rear suspension (mm) | 993/1247 |
gearbox | 6 speed manual |
Wheelbase (mm) | 3350 |
Tyre specification | 215/75R16LT |
air conditioner | 1 set |
Emission standard | euro6 |
Driving mode | Rear-wheel drive |
【Caution Light】
You can choose different styles of caution lights for any type of ambulance. The forehead is equipped with a warning light, and the forehead is equipped with an LED screen mounted warning light.
【Power Supply】
Integrated circuit integrated control and protection system of the ambulance. Strip light on top. Rectangular disinfection lamp.
【Negative Pressure Stretcher】
The ambulance can equipped a negative pressure stretcher which can make air from outside into the bin and discharge air after treatment in order to infect another person.
【Medical Cabinet】
The ambulance can be equipped with medical equipment cabinets, stretchers, oxygen bottles and other special rescue equipment.
CLW Group is a top 500 corporation in China,focusing on special vehicles manufacturing since 1988.The company has an annual production capacity of 100.000 special trucks including LPG tanker trucks,fire trucks,water trucks,garbage trucks,truck-mounted crane,tow trucks,ambulance and other special vehicles.
1.Our company ChengLi Special Automobile Co.,LTD has manufactured special truck for decades.
2.Our company possesses some advanced technologies and mature craftworks.
3.The truck produced by us has high quality and low price.
4.Our trucks are equiped with high quality and efficient equipments.
5.Our trucks are completely produced according to your demands and needs, they are special, professional and unique for you.
1. Q: How about the quality of trucks of your factory?
A: Our trucks get ISO 9001: 2008 and CCC, B&V and other related certificates. The chassis and spare parts come from the original manufacturers with anti-fake label.
2. Q: How many years of your company's service, especially after-sale service?
A:CLW group has been in this field for nearly 15 years and has strong production and distribution capability, we can produce your products in 15 working days. We offer 1 year after-sale service.
3. Q: Is there any advantages of your price?
A: CLW Group is one of the most important suppliers of Sinotruk, Shacman, Dongfeng, FOTON and FAW, which provides guarantees for reasonable price and good quality.
4. Price term: FOB, CIF.
5. Payment: 30% deposit after order confirmation, 70% balance should be paid before delivery. All are by T/T, L/C.
6. Delivery time: 25 working days after payment is received.
7. Standard Steering: Left-hand drive, if you need Right-hand drives, please inform us, will make special order for you.
