We can supply 2-18CBM Compactor garbage truck and the China compactor garbage trucks already were exported to more than 30 countries. Competitive price with high quality always accompany with our compactor garbage truck.
Rubbish compactor parameters
Item | Specification |
Cab | FVR cab reversible with air conditioner |
Front axle | 6.3t |
Rear axle | 13 tons |
Transmission | MLD six-speed transmission |
Vehicle frame | Straight through reinforced beam |
Tires | 295/80R22.5 type vacuum tires 6 |
Power take-off interface | Yes |
Power take-off | Yes |
Front/rear overhang (mm) | Front: 1335. Rear: 2665 |
Departure angle | Front:20. Rear:17 |
Suspension | Steel plate spring 9/7+7 |
Leaf spring | 9 front, 7+7 rear |
Number of axles | 2 |
Wheelbase (mm) | 4500 |
Number of tires | 6 |
Wheelbase (mm) | 1960/1860 |
Drive type | 4*2 |
Engine | 6HK1-TCL 240hp |
Emission standard | Euro V |
Suspension | Steel plate spring |
Driving style | Steering wheel type, left-hand drive |
Brakes | Drum type |
Braking system | Air brake |
Spare tire carrier | Yes |
Light | Yes |
Tool box | Yes |
Voltage | 24V |
Color | according to customer's requirement |
Material and thickness of garbage compartment | Q345 low alloy anti-corrosion and wear-resistant plate (manganese steel) side 5mm, bottom 5mm, side plate 5mm |
Compartment shape | Arc-shaped compartment |
Emergency stop button | Yes |
Safety control system | Yes |
Sewage tank | Yes |
The tail electric control device | Yes |
Remarks | Adopt domestic famous brand oil cylinder, high-density high-pressure oil pipe, multi-way valve and oil pump, small floor bucket |
CLW Group is a top 500 corporation in China,focusing on special vehicles manufacturing since 1988.The company has an annual production capacity of 100.000 special trucks including LPG tanker trucks,fire trucks,water trucks,garbage trucks,truck-mounted crane,tow trucks,ambulance and other special vehicles.
We can produce many kinds of garbage trucks, including skip loader garbage truck, compactor garbage truck, garbage collection truck, garbage transportation truck, container garbage truck, hydraulic lifter garbage truck, self-loading garbage truck, arm-roll garbage truck, hanging bin garbage truck, dump garbage truck, hermetic garbage truck, sealed garbage truck, arm shaking garbage truck, etc.
The registered trademark of which is "Chengliwei", and the product code is "CLW". It's the important partner of Dongfeng and Jiefang. And mainly engaged in manufacturing all kinds of special vehicles and selling full vehicle and fittings to large-scale manufacturers.
The company is a hightech enterprise in hubei province and has passed the certification of ISO9001,ISO16949,GJB9001 and CCC authentication of automobile products.
1.Our company ChengLi Special Automobile Co.,LTD has manufactured special truck for decades.
2.Our company possesses some advanced technologies and mature craftworks.
3.The truck produced by us has high quality and low price.
4.Our trucks are equiped with high quality and efficient equipments.
5.Our trucks are completely produced according to your demands and needs, they are special, professional and unique for you.
1. Q: How about the quality of trucks of your factory?
A: Our trucks get ISO 9001: 2008 and CCC, B&V and other related certificates. The chassis and spare parts come from the original manufacturers with anti-fake label.
2. Q: How many years of your company's service, especially after-sale service?
A:CLW group has been in this field for nearly 15 years and has strong production and distribution capability, we can produce your products in 15 working days. We offer 1 year after-sale service.
3. Q: Is there any advantages of your price?
A: CLW Group is one of the most important suppliers of Sinotruk, Shacman, Dongfeng, FOTON and FAW, which provides guarantees for reasonable price and good quality.
4. Price term: FOB, CIF.
5. Payment: 30% deposit after order confirmation, 70% balance should be paid before delivery. All are by T/T, L/C.
6. Delivery time: 25 working days after payment is received.
7. Standard Steering: Left-hand drive, if you need Right-hand drives, please inform us, will make special order for you.
